Amana Tool RC-2248 Insert Carbide Mini Spoilboard Surfacing, Rabbeting, Flycutter, Slab Leveler & Surface Planer 1-1/2 Dia x 15/32 (12mm) x 1/4 Inch Shank Router Bit
- Mini insert carbide spoilboard surfacing & rabbeting router bit great for cutting tight corners and surface planing.
- Also suitable for router sled machines,
- Make sure that your router sled is fully stable and squared.
- Perfect for:
- Resurfacing spoilboards using CNC
- Planing large glued up panels using CNC
- Surfacing and finishing wood using timber slab machines
- Rabbeting or slotting
- Designed for planing & rabbeting the following materials:
- MDF
- Fiberboard
- HDF/LDF
- Balsa Core*
- Epoxy (Epoxy Resins)*
- High Density Urethane (HDU Board)*
- Plastic/Acrylic*
- Plywood/Chipboard*
- Hardwood/Softwood*
- Ultra-High-Molecular-Weight Polyethylene (UHMWPE)*
- *For optimal results and maximum insert life, replace inserts with optional general purpose knives #AMA-12 (sold separately).
- Featuring:
- 4-sided solid carbide insert knives
- Exclusive carbide grade for highest quality of cut
- Maximum cutting efficiency
- Faster material removal process
- These industrial router bits feature solid carbide insert knives with four cutting edges that allow users to rotate the knife when one side becomes dull providing the highest-quality finish available on woodworking tools.
- Proper torques rating to tighten down screws is 2-3Nm Torques.
- Vectric and Fusion 360 compatible tool files for RC-2248 available for download, click here.
- Included MDF Knives (2 Required)
- Optional General Purpose Knives (2 Required)
- Optional Solid Wood Diamond-Like Carbon (DLC) Knives (2 Required)
- Torx Screw (2)
- Torx Key
- HMA-12
- AMA-12
- AMA-12-DLC
- 67117
- 5005
- RC-2248 DXF
- File Size : 463.77 KB
More Information
| Cutting Diameter |
1-1/2 |
| Shank |
1/4 |
| Cutting Length |
12mm (15/32) |
| Overall Length |
1-11/16 |
| Maximum RPM |
24000 |
